Thursday, January 27, 2011

HyparSrf_9_A,B,C revisions

7 x 6 panels
lowered in center
attempt to lower 5th panel to touch in 2 places (this can be fine tunned)
back curves out 5' from face of the wall in plan
variations in front condition



A- front similar to the back, full length of site, curved in 5ft and angled slightly






B- front similar to the back, curved in 5 ft in plan, width of only the front gate






C- "tear drop" front, angled back 45 degrees





Wednesday, January 26, 2011

HyparSrf_9

7 x 7 panel division
curved at top/back
"teardrop" front,
up/down +/- 1 ft everywhere except ends.
